538 Cable Fittings

Morse Cable Fittings

SERIES 30 SERIES 40 SERIES 60
10-32 Thread 1/4"-28 Thread 5/16"-24 Thread
Ball Joints 31799-001 - Quick-Release type, stud is 7/16" long 29104 - Quick-Release type, stud is 9/16" long with 38491 - Solid type, stud is 11/16" long with 5/16"-
with #10-32 UNF threads. 7/8" from center of stud to 1/4"-28 UNF threads. 15/16" from center of stud to 24 UNF thread. 1-1/8" from center of stud to end of
end of barrel. Complete with nut and lockwasher. end of barrel. Complete with nut and lockwasher. barrel. Complete with nut and lockwasher.
31126 - Quick-Release type, stud is 9/16" long with 32267 - Quick-Release type, stud is 7/8" long with 29108 - Quick-Release type, stud is 7/8" long with
1/4"-28 UNF threads. 15/16" from center of stud to 5/16"-24 UNF thread. 1-3/16" from center of stud to 5/16"-24 UNF thread. 1-1/8" from center of stud to
end of barrel. Complete with nut and lockwasher. end of barrel. Complete with nut and lockwasher. end of barrel. Complete with nut and lockwasher.
35242 - Quick-Release type, stud is 7/8" long with
5/16"-24 UNF threads. 1-1/8" long from center of stud
to end of barrel. Complete with nut and lockwasher.
Clevis 31800 - Fits 3/16" thick lever with 3/16" dia. hole. 29025 - Fits 9/32" thick lever with 1/4" dia. hole. 29132-001 - Fits 11/32" thick lever with 5/16" dia.
hole. Length from center of pin to barrel end is 2-1/4".
Length from center of pin to barrel ends is 1-9/16". Length from center of pin to barrel end is 2". 38820 - Fits 1/2" thick lever with 7/16" dia. hole.
31125 - Fits 9/32" thick lever with 1/4" dia. hole. 42212 - Fits a 11/32" thick lever with 5/16" dia. hole. Length from center of pin to barrel end is 2-7/8".
Length from center of pin to barrel end is 2". Length from center of pin to barrel end is 2-1/4".
33395 - Fits 11/32" thick lever with 5/16" dia. hole.
Length from center of pin to barrel end is 2-1/4".
Pivots 45583 - Fits 1/8" thick lever with a 3/16" dia. hole. 39110 - Fits 1/8" thick lever with 1/4" dia. hole. 43195 - Fits 7/16" thick lever with a 3/8" dia. hole.
31029 - Fits 1/8" thick lever with 1/4" dia. hole. 45199 - Fits 1/8" thick lever with 5/16" dia. hole. 40889 - Fits 1/2" thick lever with 1/2" dia. hole.
31539 - Fits 3/16" thick lever with a 1/4" dia hole. 43314 - Fits 9/64" thick lever with a 1/4" dia hole. 44643 - Fits 5/32" thick lever with 5/16" dia. hole.
44770 - Fits 3/16" thick lever with 7/16" dia. hole. 31537 - -Fits 3/16" thick lever with 1/4" dia. hole.
32392 - Fits 9/32" thick lever with 1/4" dia. hole. 36361 - Fits 1/4" thick lever with 1/4" dia. hole.
39890 - Fits 5/16" thick lever with 1/4" dia. hole. 39804 - Fits 9/32" thick lever with 1/4" dia. hole.
37691 - Fits 13/32" thick lever with 5/16" dia. hole. 42419 - Fits 3/8" thick lever with 3/8" dia. hole.
Terminal 300646 - Terminal Eye, fits 5/16" dia. pin. Length 41134 - Terminal Eye, fits 5/16" dia. pin. Length 45428 - Terminal Eye, fits 5/16" dia. pin. Length from
Eye from center of hole to barrel end is 1". from center of hole to barrel end is 1-3/8" (Fits inside center of hole to barrel end is 1-5/8". Fits 5/16" yoke.
300561 - Terminal Eye, fits 3/16" dia. pin. Length 5/16" yoke)
from center of hole to barrel end is 1". 37639 - Terminal Eye, fits 5/16" dia. pin. Length
from center of hole to barrel end is 1" (aluminum)
Fig. 9439 No. 67-19 - E-Clip used on MN
and MT-3.
Terminal 300965 - Pivot Pin, for terminal eye No. 300646 -
Eye Pin Stud is 1/4"-28 UNF x 5/8" long (for 1 or 2 eyes).
301456 - Terminal Eye Pin Kit-contains terminal eye
pin E-ring, nut, and washer.
Clamps & 31509 - Cable Clamp 7/32" dia. holes on 1" centers. 31532 - Cable Clamp, two 7/32" dia. holes on 36733 - Cable Clamp, two 9/32" dia. holes on 1-
Fasteners 32010 - Cable Clamp 7/32" dia. holes on 7/8" centers. 1" centers. 1/4" centers.
31538 - Shim, for use with clamp 31509. 7/32" dia. 21227 - Cable Clamp, four 7/32" dia. holes on 1" centers. 37884 - Shim, for use with clamp 36733 two 9/32"
holes on 1" centers. dia. holes on 1-1/4" centers.
35777 - Shim, for use with clamp 32010, 7/32" dia. 37885 - Clamp 36733 and Shim 37884.
holes on 7/8" centers.
35531 - Dual Cable Hook Clip, for two cables. Six
3/16" dia. holes on 3/4" centers, 3/8" apart.
36174 - Cable Hook Clip, six 3/16" diameter holes on
1/2" centers, 3/8" apart.
37664 - 30L Series Conduit Clamp — See Fig. 2114
CABLE FITTINGS Note: Bold Underlined Numbers are Stocked 44386 - Cable Brake 44386 - Cable Brake
44386 - Cable Brake
Cable Break

FIG 4259

No. Each No. Each No. Each No. Each No. Each
SERIES 30 - 10-32 THREAD
31029 $18.25 31539 $14.70 33395 $20.50 37691 $12.90 300646 $5.80
31125 18.25 31799-001 16.55 35242 57.30 39890 22.60 Fig. 3472 300561 15.35
31126 15.90 31800 18.05 35531 36.90 44386 26.50 300965 13.40
31509 1.80 32010 5.50 35777 6.40 45583 12.60 301456 16.20
31538 1.65 32392 14.25 36174 14.30 Fig. 9439 67-19 0.15
SERIES 40 - 1/4"-28 THREAD
29025 21.05 31532 3.10 32267 27.70 39110 13.70 42212 23.45
29104 25.55 31538 1.65 37639 13.40 41134 21.75 44386 26.50
SERIES 60 - 5/16"-24 THREAD
29108 46.15 36733 4.25 37885 10.15 38820 43.25
29132-001 22.10 37884 6.10 38491 15.20 44386 26.50
