542 Trim Tabs and Controls

BOLT Electric Trim Tabs
with Adjustable Upper Hinge

BRC4000
BOLT129
HYDBOLTCON
BEA3000
BCI8000 FIG 3853 BCN6000
BOLT Electric Trim Tabs combine cutting-edge technology with a robust and water-tight actuator. Wires are concealed and protected
through the adjustable upper hinge — there are no exposed wires to the marine environment. The main seal is located high to pro-
tect against marine growth and water intrusion failures. Installation is fast — no need to disassemble parts of the actuator. Single
actuator use, due to the inability to synchronize two electric actuators on the same tab. For: Trailered boats from 17-28 feet. The kit
INCLUDES: 2-12-Volt actuators with 6-ft. wire harnesses and waterproof connectors, two stainless steel trim planes and mounting
plates. One control box with 3-ft. wire harness and diagnostics, and 2-20-ft. harnesses with waterproof connectors. BCI8000 com-
bines three features into one compact control — Rocker switch control, trim tab position indicator and Auto Tab Retractor. Highly
accurate and features variable intensity LEDs for night or day. Has water-resistant keypad and connectors and is completely plug and
play, no need to run additional wiring back to the transom. The control box incorporates innovative LED status indicators simplifying
installation and troubleshooting. HYDBOLTCON – Quick and easy conversion from standard Bennett hydraulic single actuator sys-
tems (A1101A) using your existing wiring, rocker switch and trim planes. No rewiring or drilling of new holes required. Volt: 12 DC.
No. Each Description
BOLT129 $583.15 12" x 9" Electric Trim Tab System
BOLT189 625.95 18" x 9" Electric Trim Tab System
BOLT1212 625.95 12" x 12" Electric Trim Tab System
BCI8000 422.65 BOLT Control with LED Indicators
HYDBOLTCON 374.50 Hydraulic-To-Bolt Conversion Kit
BEA3000 240.75 BOLT Adjustable Actuator
BCN6000 208.65 BOLT Control – No LED Indicators
BRC4000 101.65 BOLT Euro Rocker Switch
Controls Sold Separately
Performance Sport Tabs Bennett Controls
ST16, ST12 and ST9

TRIM TABS AND CONTROLS This system offers strength, durability, and good looks. Tabs are ES2000 Euro-Style Rocker Switch Control is ergonomically
ST16
ST9
Euro-Style Rocker Switch
Electronic Indicator Control
ES2000
EIC5000
FIG 3859
FIG 3858
constructed of thick, 12-gauge stainless steel with vertical stiff-
eners for extra strength. The inboard edges of the tab are
tapered to prevent lower unit interference and cavitation. Uses
only 12" of transom per side. INCLUDES euro-style rocker
designed, water-resistant and provides a positive "click" when
switch control. Engineered for speeds 40 to 60 mph. The ST16 is
the trim tabs are engaged. Its lock-out feature prevents user
the largest Sport Tab and is appropriate for use on boats 25 feet
from pressing down on opposite directions at the same time.
and above. The ST12 is the ideal performance addition for boats
The control is easy to install, fitting into any existing Bennett
below 25 feet. ST9 is single cylinder Sport Tab that offers the
same structural integrity as the ST16 and ST12, but is designed
saves space on the helm with three features combined into
one sophisticated control — the popular Bennett rocker switch
for boats slightly less demanding. Kit also INCLUDES hydraulic
control, trim tab indicator and the auto tab retractor. Water-
power unit, and all necessary wiring, tubing and hardware.
resistant, highly accurate and features variable intensity LEDs
Per Plane
No. Complete Size Volts Boat Length Actuators 2-1/2" rocker switch hole. EIC5000 Electronic Indicator Control
for night or day. Features a relay module mounted near the
ST16 $1243.35 12" x 16" 12 25 ft + up 2 transom, which simplifies installation by reducing the number
ST12 1149.20 12" x 12" 12 Below 25 ft. 2 of wires to run to the helm.
ST9 908.45 12" x 9" 12 Below 21 ft. 1 No. Each Control Type Hole Size
IMPORTANT NOTE: Performance Sport Tabs are not for off- ES2000 $99.90 European Style Dual sq. Rocker Only 2"
shore or inland racing. Many factors determine the appropriate EIC5000 426.95 Dual Rocker w/Indicators 2"
size and type of trim tabs for high horsepower boats. Therefore, EIC101 168.00 12V EIC Relay Module
special care and consideration is required in trim tab selection. EIC102 168.00 24V EIC Relay Module
For Shell ATF Dextron III Fluid — See Fig. 7977
