Bennett Electro-Hydraulic Trim Tabs

Aircraft-Type Planing Control, Engineered in Correct Designs and Sizes for Boats 10 to 120 feet in Length

Pitch Correction Roll Correction

Standard 9" Chord THE BENEFITS OF BENNETT TRIM TABS 12" Chord
Plane Span Hull Length • Reduced Fuel consumption • Greatly improved visibility Limited Transom Space – Individual tab size
should be slightly more than 1" per foot of boat
(APPROXIMATE) • Reduced laboring of engines • Reduced wake length. (Ex: 22' boat, 24" tab per side). In situa-
12" (10") 15' - 24' • Reduce hull stress • Increased speed tions where a boat is equipped with dual out-
18" (16", 14") -19' - 24' 18' - 24' • Elimination of porpoising • Reduced pounding
24" (22", 20") - 22' - 27' 20' - 26' boards or dual I/Os, this rule cannot be adhered
30" 25' - 30' to for reasons of limited transom space.
36" - 28' - 34' 28' - 36' Extra Lift – Certain boats require greater lift in
42" -32' - 38' 32' - 42' THE DROP FIN MODEL is designed to trap the the stern. The 12" chord provides more surface
48" - 36' - 44' 35' - 48' area of trim tab, thereby deflecting more water
54" - 42' - 50' 40' - 54' water under the tab and prevent it from escaping out and providing greater lift. The following boats
Larger Planes Provide Greater Efficiency of the sides. In doing so, pressure under the tab should always use a 12" chord: All displacement
increases, providing more lift and making any given or semi-displacement hulls; All boats with a cruis-
size tab more effective. Available in 12" chord only. ing speed of less than 15 mph; All boats over
50'; All boats unusually heavy in the stern.
Running uphill (squatting) labors the engines and wastes fuel. Bennett Trim Tabs lift the stern, putting the boat on its designed running lines for
maximum speed and efficiency. They consist of a pair of stainless steel afterplanes, a hydraulic power unit, a pair of hydraulic cylinders (actuators).
**Complete Kit DOES NOT INCLUDE Control — Dashboard control must be ordered separately. Units use automatic transmission
fluid. See Fig. 7977.
SPECIFY ES2000 OR EIC5000 CONTROL WHEN ORDERING, IF DESIRED — See Fig. 3858
FIG 3857 FIG 102

Actuators Spare Trim Plane Assembly*
No. Complete** Voltage Per Plane Mount No. Each
129 $679.45 12 1 Transom TPA129 $140.20
169 738.30 12 1 Transom TPA169 156.25
189 738.30 12 1 Transom TPA189 156.25
249 768.30 12 1 Transom TPA249 172.30
309 805.70 12 1 Transom TPA309 192.60
369 833.55 12 1 Transom TPA369 210.80
429 880.60 12 1 Transom TPA429 236.50
1212DF 768.30 12 1 Transom w/Drop Fin TPA489 271.80
1212UF 739.40 12 1 Transom w/Up Fin TPA128UF 140.20
1812 768.30 12 1 Transom TPA1212DF 172.30
2412 797.15 12 1 Transom TPA1212UF 158.40
3012 833.85 12 1 Transom TPA1812 172.30
4212 942.70 12 1 Transom TPA2412 188.35
TPA3012 209.75
TPA3612 235.40
TPA4212 270.70 TRIM TABS

A FULL 5-YEAR GUARANTEE ON TRIM TAB UNITS AND SPARE PARTS
