Trim Tab Position Indicator Auto Tab Retractor

WHILE
SUPPLIES
LAST

Typical Installation

TPI2000
FIG 9031

Features & Benefits
• Accurate L.E.D. Visual Readout This automatically retracts the trim tabs when the boat's igni-
• Real time sensors and memory tion is turned off. This reduces the risk of damage from fork-
• Adjustable Light Intensity for Night or Day lifts, trailers and dry storage racks. Relieves hydraulic pressure
• Low-Profile, Waterproof Case – 3-Year Warranty when tabs are not in use.
• Small – only 2-1/2" x 3-3/8" x 3/4" and fits standard gauge hole No. Each Volts Length x Width x Depth
AR512 $86.90 12 DC 3" x 2" x 1-1/4"
AR524 86.90 24 DC 3" x 2" x 1-1/4"
FIG 6038
Complete Actuator Assemblies
The water-resistant TPI helm display accurately shows
deflection percentage of each trim tab, and the LED bright-
ness is adjustable for any lighting condition. Works with all
Bennett trim tabs. Standard kit for single station INCLUDES
one helm display, hardware kit, and two actuator upper
hinges with sensors.
No. Each Type Description A1101A
TPI2000B $520.20 Dual Tab Position Indicator Kit
CC3003S 39.25 Starboard Actuator Upper Hinge
with Sensor FIG 200

Hydraulic Power Unit A1101A Complete actuator assembly INCLUDING upper and
lower hinge (18 thru 23 in Fig. 200 parts breakdown). A1101A
Standard Actuator Assembly. 13-3/4" length, 2-1/2" stroke.
A1200S Small Actuator Assembly. 11-3/4" length, 2-1/2" stroke.
No. Each Description
A1101A $107.50 Standard Actuator Assembly
A1200S 107.50 Small Actuator for Tournament Tab

Trim Tab Zinc TRIM TAB ACCESSORIES

FIG 3860

This unit creates hydraulic pressure to lower and raise the trim
tabs. It employs two solenoid valves to direct the flow of fluid
to the actuators. The solenoid valves lock tightly to secure the
tabs in place. Strength to lower and hold even the largest tabs
in place. Lexan cover protects electrohydraulic unit from occa-
sional wash down and translucent reservoir allows fluid check
at a glance. Measures 4"W x 7-1/2"H x 5-1/2"D. Uses automatic FIG 4042
transmission fluid. INCLUDES pump, solenoid valves, reser-
voir and cover. Installs easily with sturdy mounting bracket
(sold separately Fig. 200 No. H1179.) Trim tab kit for most popular trim tabs. Uses existing holes in
No. Each Description tabs. INCLUDES two zincs, four 1/4"-20 x 1-1/4" stainless screws.
HPU12 $393.15 12V Power Unit No. Each Size
HPU24 415.95 24V Power Unit BNT $28.30 3-13/16" L x 1-1/8" W
For Shell ATF Dextron III Fluid — See Fig. 7977
