ESCAPE AND VENTILATION HATCHES

Type LIBERO (AII)
Still going strong
These hatches have a hand polished and anodised aluminium frame
with a 1 /4” or 2 /16” (32 or 55 mm) corner radius and a /8” (10 mm)
1
3
3
‘dark smoke’ coloured acrylic lid. The escape and deck hatches come
with adjusters allowing the lid to be held open at almost any angle up
to 90º. A special friction hinge allows the ventilation hatches to remain
open at any angle up to 180º. Type LIBERO is suitable for design
category A, Area II.

59
48 4
9 LIB
Maximum height (incl. dogs)

Escape hatches with adjusters up to 90º
External dimensions Cut-out dimensions Number of
Type Cut-out radius R (mm)
A x B inches (mm) C x D inches (mm) handles
LIB6232L 26 /4 x 26 /4 (680 x 680) 24 /16 x 24 /16 (620 x 620) 32 2
7
3
3
7
LIB6255L 26 /4 x 26 /4 (680 x 680) 24 /16 x 24 /16 (620 x 620) 55 2
3
7
7
3
LIB5032L 22 /16 x 22 /16 (560 x 560) 19 /16 x 19 /16 (500 x 500) 32 2
11
1
1
11
1
1
LIB5055L 22 /16 x 22 /16 (560 x 560) 19 /16 x 19 /16 (500 x 500) 55 2
11
11
LIB4155L 18 /2 x 18 /2 (470 x 470) 16 /8 x 16 /8 (410 x 410) 55 2
1
1
1
1
Deck hatches with adjusters up to 90º
External dimensions Cut-out dimensions Number of
Type Cut-out radius R (mm)
A x B inches (mm) C x D inches (mm) handles
LIB3732L 22 1 /16 x 16 15 /16 (560 x 430) 19 11 /16 x 14 9 /16 (500 x 370) 32 2
LIB3755L 22 1 /16 x 16 15 /16 (560 x 430) 19 11 /16 x 14 9 /16 (500 x 370) 55 2
LIB3232L 20 1 /16 x 14 15 /16 (510 x 380) 17 11 /16 x 12 5 /8 (450 x 320) 32 2
LIB3255L 20 1 /16 x 14 15 /16 (510 x 380) 17 11 /16 x 12 5 /8 (450 x 320) 55 2
Ventilation hatches with friction hinge up to 180º
External dimensions Cut-out dimensions Number of
Type Cut-out radius R (mm)
A x B inches (mm) C x D inches (mm) handles
LIB3432L 15 3 /4 x 10 1 /16 (400 x 255) 13 3 /8 x 7 43 /64 (340 x 195) 32 1
LIB2032L 10 1 /4 x 10 1 /4 (260 x 260) 7 7 /8 x 7 7 /8 (200 x 200) 32 1
