ESCAPE AND VENTILATION HATCHES

Type MAGNUS (AI)
Heavy duty ocean hatch
MAGNUS hatches have a satin sheen anodised frame profile with a
/8” (10 mm) thick ‘dark smoke’ coloured acrylic and are designed for
3
ocean use, design category A, Area I. These hatches can be opened from
the inside or outside through 180º with almost no obstructions in the
opening. They have a ventilation position and can be locked completely
watertight. The cut-out sizes of this type match the
market-based dimensions.

VETUS does not recommend the use of a Magnus hatch as a means of
escape on multihulls below or near the waterline. The A1 hatch meets
the Recreational Craft Directive (RCD2013/53/EU), however we cannot
guarantee water tightness for this specific position. Please contact our
glazing team for further information.

47 15 MAG
38
18

Maximum height (incl. dogs)

Escape hatches
External dimensions Cut-out dimensions Number of
Type
A x B inches (mm) C x D inches (mm) handles
MAG6363SL 26 /4 x 26 /4 (679 x 679) 24 /16 x 24 /16 (627 x 627) 4
3
11
11
3
MAG5151SL 22 /16 x 22 /16 (559 x 559) 19 /16 x 19 /16 (507 x 507) 4
15
3
3
15
MAG4747SL 20 /16 x 20 /16 (522 x 522) 18 /2 x 18 /2 (470 x 470) 2
9
1
1
9
Deck hatches
External dimensions Cut-out dimensions Number of
Type
A x B inches (mm) C x D inches (mm) handles
MAG4242SL 18 /16 x 18 /16 (473 x 473) 16 /16 x 16 /16 (421 x 421) 2
11
9
11
9
MAG5038SL 22 x 16 /4 (559 x 429) 19 /16 x 14 /16 (507 x 377) 2
13
15
1
MAG4633SL 20 /16 x 14 /16 (509 x 379) 18 x 12 /8 (457 x 327) 2
7
15
1
Ventilation hatches
External dimensions Cut-out dimensions Number of
Type
A x B inches (mm) C x D inches (mm) handles
MAG2626SL 12 /16 x 12 /16 (312 x 312) 10 /4 x 10 /4 (260 x 260) 1
1
5
1
5
MAA3520L 15 /16 x 10 (399 x 254) 13 /16 x 7 /16 (347 x 202) 2
11
15
11
A
C
R43
D B
