P. 275
CUSTOM MADE BOAT GLAZING
Screw-on range 31 26 35
Specifications
• Particularly suitable for wooden superstructures
• Suitable for all panel thicknesses
• Supplied with a black, white or grey strip to cover the screws 42
• With corner radii 2 /16”, 3”, 3 /12” or 4 /8” (65, 75, 90 or 105 mm) or 42 12 43 12
1
9
1
mitred corners 23
• Glass thickness: /4” (6 mm) or /16” (8 mm) 0 - 33 mm 7 - 43 mm
1
5
Cover strip outside Screw-on range inside
Comfort range
Specifications
• Uses an aluminium clamp profile, fastened from inside by screws
through the supplied aluminium counter flange (therefore no screws
are visible from the outside of the boat)
• Suitable for panel thicknesses between /8” and 1 /16” (3 and 33 mm)
1
5
7
(fixed glass), /8” and 1 /16” (3 and 37 mm) (sliding glass) or /8” and
1
1
1 /8” (3 and 42 mm) (double glass)
5
• Supplied with a black, white or grey strip to cover the screws
• With corner radii 2 /16”, 3”, 3 /12” or 4 /8” (65, 75, 90 or
1
1
9
105 mm) or mitred corners
• Available glass thicknesses: /4”, /16” and /8”
1
3
5
(6, 8 and 10 mm for single glass or
combined for double glass Cover strip outside Comfort range inside
Exclusive range
Specifications
• Uses an aluminium clamp profile, fastened from inside by screws
through the supplied aluminium counter flange (therefore no screws
are visible from the outside of the boat)
• Suitable for panel thicknesses of /4” to 1 /16” (7 to 43 mm)
1
11
• Supplied with a black, white or grey strip to cover the screws
and a seal for fitting
• To prevent condensation on the inside glass pane and window frame,
the Exclusive range uses an (insulation bridge) insulated edge seal
• Available as fixed or fully hinged versions with double glass only
• With corner radii 3”*, 3 /12” or 4 /8” (75*, 90 or 105 mm) or
1
1
mitred corners
• Available glass thicknesses /4”, /16” and /8” (6, 8 and 10 mm)
1
3
5
can be combined for the double glass. The standard is outside Exclusive range inside
two panes, each /4” (6 mm) thick
1
Cover strip
*Except hinged windows
