CUSTOM MADE BOAT GLAZING

Sliding cabin entry
Easy sliding!
Equipped with bearing runners this single unit cabin
entry opens and shuts very easily. In order to keep
the sliding door in its open position an end-lock is
mounted. Available with mitred corners, acrylic pane 90º
and angles from 90-180 degrees. 180º -
All cabin entries are suitable for design category A,
Area IV.

Hinged doors
For boating in heavy weather, these hinged doors are fitted with a double seal for
protection against flooding. The door's upper section can be single or double glazed, or
fitted with an opaque panel (tinted glass). Available with mitred or rounded corners.

All doors are suitable for design category A, Area IV.
Specifications
• Corner radius: 5 /8” (130 mm)
1
• Door thickness: /32” (20 mm)
25
• Panel thickness: /8” - 1 /64” (3 - 48 mm)
57
1

Type FBH - Fly Bridge Hatch
Slim and sleek design
To cover the opening between the deck and fly bridge we offer you:
the FBH (Fly Bridge Hatch). The slim and sleek design of the FBH fits perfectly on
modern type boats. This FBH can be tailor-made up to 24 /16” (630 mm) width
13
and 51 /16” (1300 mm) long and features /2” (12 mm) dark smoke acrylic on a
3
1
polished and anodised aluminum frame. With style and flair it merges flawlessly
on the fly bridge of your vessel.
Specifications
• Privacy tinted fly bridge hatch
• /2” (12 mm) thick ‘dark smoke’ acrylic
1
• Polished and anodised high grade aluminium frame
• Ergonomic and precision engineered handles
• Hatches are available in both rectangular and square shapes
• Easy to clean and maintenance-free design
• Suitable for design category A, Area II

External dimensions Cut-out dimensions Radius
Type
inches (mm) inches (mm) inches (mm)
FBH up to 27 /16 x 54 /16 (703 x 1373) up to 24 /16 x 51 /16 (630 x 1300) 1 /16 (43) FBH
11
3
11
1
13
Creators of Boat Systems 277
