CUSTOM MADE BOAT GLAZING

Windscreens
Choose your style
Our custom made windscreens are constructed from polished and anodised or
powder-coated aluminium extrusions. The toughened glass can be supplied in the
tints ‘clear’, green, grey, or bronze. The upper edges of the side screens can be
made with a large radius curve. Below you see 2 installation possibilities.

Installation option 1

There are two ways to secure the windscreen to the superstructure: either hinged (A) or fixed (B),
see drawing.
For boats which often pass under low bridges, the windscreens can be hinged so each section can be
lowered to the deck to reduce the craft’s air draft.

Installation option 2
The standard profile along the top edge of the windscreen is as shown in drawing A. If a spray hood is to
be fitted, we can install the profile shown in drawing B, to which standard canvas fittings such as snaps
or twist-locks can be attached.

Fastening system for hinged windscreen

Flush Panoramic Sunroof
Ultimate benefits of a solid glass roof
Our panoramic sunroof is produced using the latest state-of-the-art
techniques, components and materials, operating both silently and smoothly.
You can enjoy the sun and the ocean breeze by opening the panoramic
roof (measuring 78 /4 x 84 /8” - 2000 x 2150 mm) or keep the weather out by
5
3
simply closing it.

Model Flush Panoramic Sunroof
5
Outside dimensions 78 /4 x 84 /8” (2000 x 2150 mm)
3
Roof radius 39.3 ft (12 m)
Weight (excl. glass) 187.3 lbs (85 kg)
Weight (incl. glass) 385.8 lbs (175 kg)
Voltage 230 V / 260 W

278 Glazing systems - Want to know more? Visit www.vetus.com
