ELECTRIC VENTILATORS
Type FAN

Extremely low energy consumption and noise level
This barely audible electric ventilator is specified for saloons, cabins, galleys and toilets and is also ideal for heat extraction
near a refrigerator. It can be installed in both ceilings and bulkheads. It can be used in combination with VETUS deck
ventilators UFO and UFOTR (see page 290). With its long-life motor it can operate for at least 50.000 hours. VETUS
recommends that every area should have an air-exchange rate of 3 to 4 times per hour.

FAN12

FAN24

Specifications Type Description Volt
• Available in 12 or 24 Volt (consumption 0,19 A
or 0,11 A) FAN12 Electric ventilator 12
• Capacity 42 cfm (72 m /hour) FAN24 Electric ventilator 24
3
• Provided with a 2-speed switch

EXTRACTION VENTILATORS
Type TWINLINE

The perfect heat extractor
The purpose of these ignition protected (IP67) extraction ventilators is to extract the heat from the engine room when the
engine is not running or, when a petrol/gasoline engine is installed, to extract any possible petrol/gasoline fumes prior to
starting the engine(s).

Specifications
• Complies with ISO 9097 Marine Standard C
• Hose may be connected to Scirocco or A
Typhoon Shell ventilators

Note
VETUS does NOT recommend using
extraction ventilators to provide air to
the main engine(s)! B D

TWINLINEA TWINLINEB

TWINLINEC TWINLINED

A B C D Capacity I.D. hose
Type Volt - Amp*
3
inch (mm) inch (mm) inch (mm) inch (mm) (m /min) Ø inch (mm)
TWINLINEA 3 / (88.5) 3 / (92.5) 3 (76) 5 / (128) 5 3 (76) 12 V - 2,8 A max.
1
5
1
8
16
2
TWINLINEB 4 / (116) 4 / (119) 4 (101.6) 7 / (180) 7 4 (102) 12 V - 8,0 A max.
11
9
1
16
16
16
TWINLINEC 3 / (88.5) 3 / (92.5) 3 (76) 5 / (128) 5 3 (76) 24 V - 1,6 A max.
5
1
1
2 8 16
1
9
TWINLINED 4 / (116) 4 / (119) 4 (101.6) 7 / (180) 7 4 (102) 24 V - 5,0 A max.
11
16 16 16
* When using hose 10 mtr.
