Vertical Rope/Chain Series RC10-8 • RC10-10

SPECIFICATIONS
Model RC10 (8 mm-5/16”) RC10 (10 mm-3/8”)
Maximum Pull/Lift 700 kg 850 kg
1540 lbs 1870 lbs
Static Hold 1500 kg 1500 kg
3300 lbs 3300 lbs
Chain Short Link 8 mm 10 mm
5/16” 3/8”
Rope Size (Nylon)* 14 mm - 16mm 16 mm
(3 strand or 8 plait recommended) 9/16”-5/8” 5/8”
Chain Speed 24 m/min 24 m/min
(Normal Working load) 79 ft/min 79 ft/min
Rope Speed 20 m/min 20 m/min
(Normal Working load) 65 ft/min 65 ft/min
Power Supply (DC) 12 or 24 V 12 or 24 V
Motor (Watts) 1000 W 1200 W
Net Weight 19 kg 20 kg
42 lbs 44 lbs
Hydraulic Pressure 138 bar 138 bar
2000 PSI 2000 PSI
Hydraulic Flow 20 l/min 20 l/min
5.3 USgal/min 5.3 USgal/min
Net Weight - Hydraulic 14 kg/ 42 lbs 14 kg/ 42 lbs
26 kg/ 57 lbs 26 kg/ 57 lbs
* refer to owners manual for rope size variations.
DIMENSIONS
Model RC10 (8 mm-5/16”) RC10 (10 mm-3/8”)
A 230 mm 230 mm
9 1/8” 9 1/8”
B1 89 mm 89 mm
3 1/2” 3 1/2”
B2 (with capstan) 168 mm 168 mm
6 5/8” 6 5/8”
C 170 mm 170 mm
6 3/4” 6 3/4”
D 251 mm 251 mm
10” 10”
E 272 mm 272 mm
10 3/4” 10 3/4”
F 424 mm 424 mm
16 3/4” 16 3/4”
G (Std deck clearance) ^ 100 mm 100 mm
4” 4”
H 43 mm 43 mm
1 3/4” 1 3/4”
I 66 mm 66 mm
2 5/8” 2 5/8” Important: Maxwell windlasses must be used in conjunction with a chain
J 44 mm 44 mm stopper or alternative snubbing device to take the load off the windlass while
laying at anchor. The chain stopper and alternative snubbing system should also
1 3/4” 1 3/4”
be used to secure the anchor in the fully raised position while under way.
^ extra deck clearance models available. Contact your Maxwell dealer.
STANDARD EQUIPMENT REQUIRED OPTIONS
FOR DUAL DIRECTION CONTROL 1. AutoAnchor™ Equipment
Dual Direction Solenoid (included) 2. Compact Remote
Emergency crank/clutch release 3. Foot Switches
HEIGHT MATCHED CHAIN STOPPER handle lever (included) 4. Chain Stopper
• For use with Maxwell’s rope/chain vertical Up/Down remote control panel (not included) 5. Chain Snubber
windlasses Circuit breaker/isolator panel (not included) 6. Capstan model
• Height adjusted to most effectively align
chain with the chainwheel Refer chart on page 340.
• No height adjustment plinth required
• Refer to page 335 for more information
Height Matched
Chain Stopper
