Heavy Duty

Rope/Chain Series

• The RC12HD is designed for use with 10 to 13 mm
(3/8” to 1/2”) short link chain combined with 18 to 24 mm
(3/4” to 7/8”) nylon rope

• The motor and gearbox are sized to meet typical Classification
Society test requirements for 12.5 mm U1 grade chain

• This design is particularly well suited to light duty commercial
vessels requiring high service speeds, e.g. patrol vessels, as
the reduced weight of the rope/chain combination removes
weight from the bow

• The 38 mm (1½”) mainshaft is manufactured in high strength
corrosion resistant 2205 Duplex stainless steel and the
above deck components in AISI 316 stainless steel providing
excellent corrosion resistance and highly polished finish

• The RC12HD is available with either a Heavy duty fan cooled
24VDC, 3 phase AC, Hydraulic motors of various displacements
or single phase AC motor (contact your distributor for
specifications and application). Run time and continuous pull
varies between versions (see specifications on the following
page)

• Double cone-type brake/clutch mechanism permits ‘Free Fall’
anchoring. Cone clutches, unlike dog clutches, provide smooth
progressive engagement, ensuring safe and precise operator
control
• The RC12HD features Maxwell’s revolutionary and patented
Wave Design™ chainwheel

RC12HD Capstan Version

Important: Maxwell windlasses must be used in conjunction
with a chain stopper or alternative snubbing device to take the load off
the windlass while laying at anchor. The chain stopper and alternative
snubbing system should also be used to secure the anchor in the fully
raised position while under way.
