Page 379 - Vetus

Overall Dimensions 14-8342
MARINE FITTINGS NA
Hose connector AISI 316 male G...''x...mm
Hose connector** Thread Weight
Type ØU ØB H C SW T
(G)* (inches) (lbs)
SLP1/408 ¼" 8 5 39 9 16 25 0.04
U
SLP1/416 ¼" 16 9 44 9 16 30 0.06
B
SLP3/810 3 /8" 10 7 46 10 19 30 0.06
SLP3/815 3 /8" 15 11 46 10 19 30 0.06
T SLP1/213 ½" 13 9 48 12 22 30 0.08
SW
H SLP1/216 ½" 16 12 48 12 22 30 0.08
SLP1/219 ½" 19 15 50 12 22 32 0.11
C
SLP3/416 ¾" 16 12 49 12 30 30 0.13
SLP3/419 ¾" 19 14 51 12 30 32 0.17
G
SLP3/425 ¾" 25 20 57 12 30 38 0.19
SLP125 1" 25 20 59 13 36 38 0.26
SLP132 1" 32 27 62 13 36 42 0.30
C SLP 1¼" 32 27 64 14 44 42 0.39
Weight
G… U B H SW T (grams) Item code: SLP11/432
⅜" 15 11 50.2 14.4 28 35 QA05MC-12
½" 16 11 54 14.7 31.2 40 QA05MC-15 SLP11/438 1¼" 38 32 67 14 45 45 0.44
½" 20 15 60.3 15.2 37.4 60 QA05MD-16
¾" 20 15.6 60 17 35.4 65 QA05MD-20
¾" 25 20 63 17 37 90 QA05ME-20 SLP11/238 1½” 38 32 67 16 42 43 0.51
1" 25 20.5 67 19 39.5 115 QA05ME-25
1" 30 24.8 70 18.7 43 130 QA05MF-25
1¼" 32 27.2 76 20.9 45 178 QA05MG-32 SLP11/245 1½" 45 39 73 16 53 48 0.50
QA05MF-30
1¼" 35 29.6 76 20.5 45 195
1¼" 38 32 78 21.5 48 190 QA05MG-35 Rev. 1.1 - 01-04-2014
1½" 45 39 86 22 52.7 250 QA05MG-38 2" 50 44 75 16 65 50 0.79
QA05MH-45 SLP251
2" 50 44 98.6 26 59.6 415
This drawing is the property of VETUS B.V. Copyright reserved acc. law. It is not to be copied (in whole or in part) or otherwise disclosed without the written consent of VETUS B.V.
SLP21/260 2½" 60 53 82 18 79 52 1.25

SLP376 3" 76 69 96 20 93 64 1.85
*According to ISO 228/1-G..B
** For continuous immersion in salt water, we advise against the use of brass fittings.
Ball valves** Nickel plated brass, suitable for water and diesel oil.
Thread (G)* Working Press Working temp Dimensions Weight
Type Bore
Female (inches) (bar) (° C) hxbxd (lbs)
KRAAN1/4 ¼” Full Bore 50 -20 - +170 105x50x24 0.24
KRAAN3/8 3 /8” Full Bore 50 -20 - +170 105x50x24 0.30
KRAAN1/2 ½” Full Bore 50 -20 - +170 118x58x32 0.37
KRAAN3/4 ¾” Full Bore 30 -20 - +170 118x64x39 0.57
KRAAN1 1” Full Bore 40 -20 - +170 154x86x48 0.88
KRAAN11/4 1¼” Full Bore 40 -20 - +170 154x86x58 1.32
KRAAN11/2 1½” Full Bore 32 -20 - +170 190x100x69 1.98
KRAAN2 2” Full Bore 32 -20 - +170 200x120x84 3.19
KRAAN21/2 2½” Full Bore 25 -20 - +170 270x145x102 6.61
KRAAN KRAAN3 3” Full Bore 16 -20 - +170 290x170x115 9.14
*According to ISO 228/1-G..
** For continuous immersion in salt water, we advise against the use of brass fittings.

Ball valves 3-way** Nickel plated brass, suitable for water and diesel oil.

Thread (G)* Working Press Working temp Dimensions Weight
Type Bore
Female (inches) (bar) (° C) hxbxd (lbs)
KRA1/2L ½” Full Bore 40 -10 - +100 80X160X70 1.43
KRA3/4L ¾” Full Bore 40 -10 - +100 100X205X85 3.31
KRA1L 1” Full Bore 40 -10 - +100 100X210X90 4.74
KRA KRA11/4L 1¼” Full Bore 40 -10 - +100 310X150X150 8.49
KRA11/2L 1½” Full Bore 40 -10 - +100 310X150X120 13.00
*According to ISO 228/1-G..
** For continuous immersion in salt water, we advise against the use of brass fittings.

Dimensions in mm Creators of Boat Systems 379
