COOLING WATER STRAINERS

Type FTR470
Easy mounting with 360º rotating wall bracket
This strainer is supplied with a rotating stainless steel (AISI 316) wall bracket for easy
alignment of the hose connections and clamping it securely in place. This eliminates the
need for back-bolting and dramatically simplifies the mounting process.

Specifications
• Housing of Polypropylene GF
• Filter element of HD Polyethylene 146
• Cover of Polypropylene GF/Polycarbonate FTR470

See page 55 for the water strainer installation kit.
141
Internal hose Ø Recommended input
Type
mm inches l/min.
FTR470/13 12,7 ½ 23
FTR470/16 15,9 5 /8 35 176 146
FTR470/19 19,1 ¾ 51
FTR470/25 25,4 1 91
FTR470/32 31,8 1¼ 143 141
150
FTR470/38 38,1 1½ 200

176
Type FTR33038M
This water strainer has the standard housing of the FTR330 made of the Navidurin® material.
De lid is replaced by a aluminum version. Tested until 6 bar and is suitable 150
for use under the waterline. Hose connection Ø 1 /2’’ (38,1 mm)
1
Specifications
• NAVIDURIN® material
• Easy inspection without dismanteling
• Easily removable cover
• Robust and durable filter

Internal hose Ø Recommended input
Type mm inches l/min.
FTR33038M 38,1 1 /2 200
1
FTR33038M

Type FTR1320
This type is provided with adjustable stainless steel
(AISI 316) brackets for bulkhead mounting and is available with 90 95
3 different threaded connection diameters. ø172
Hose pillars are not supplied as standard.
They can be found on page 378 of this catalogue.
Specifications
• Housing of Polypropylene GF D 297
• Filter element Polyethylene
• Cover of A.B.S.
160

D Internal recommended
Type hose Ø input l/min. D
mm inches
FTR1320/38 G 1 /2 38 1 /2 205
1
1
FTR1320/50 G 2 50 2 365
1
1
FTR1320/63 G 2 /2 63 2 /2 570 FTR1320

Creators of Boat Systems 53
