Fold Down Pole Light Mounting Base Options

Vertical Mount Base
Horizontal Mount Bases Vertical Mount Bases
with Quick Adjust Handle
Folds down 90° in either Folds down 90° in either Folds down 90° in either
direction opposite the plane direction along the plane direction along the plane
of attachment plate of the mount of attachment plate of the mount of attachment plate of the mount
2

Navigation Lights Plane

Plane
Plane

Standard Heavy Standard Heavy Heavy
Duty Duty Duty Duty Duty

Rail Mount Bases for Vertical Mount Folding Lights Perpendicular Mt.
Unique polymer block allows for easy mounting on 3/4” diameter rails
Material: Polymer
Finish: Black
Mounting Hdwe: 6 screws included (4 clamping, 2
mounting)
Fits: 3/4” diameter rails*

Features:
Both bases fit: Perko Fig. Nos. 1137, 1138, 1184, Shown
1284, 1637, 1638, 1639, & 1642 Folding Installed
Mount lights
In-Line or Axial Mt.

Rail Base OEM
Mount Dimensions Bulk Pkg.
In-Line 2-3/8” x 1-3/4” x 1-3/8” 1627000BLK
Perpendicular 2-5/16” x 3/4” x 1-1/4” 1628000BLK

* Other rail tubing diameters available by special order.
Note: Pole light and folding base not included. Fig. 1627 Fig. 1628
