LED White All-Round Navigation Lights - Removable Plug-in Mount

2-mile (USCG 2nm) Certified - Patent #D6652,161S
Use on Power Driven Vessels Under 20m (65.6 ft.) in Length
StealthSeries
Material: Polymer Top and Collar with Clear Fluted Lens
and 3/4” Aluminum Tube
Contacts: Gold Plated
Voltage: 12V LED
2 Wattage: 1.5 watts
Amperage: 0.1 amps
Base (2-Pin): Locking collar fits Figs.1045, 1046, 1047,
1059, & 1060 bases
Navigation Lights Features: The “Reduced Glare” design helps preserve night
Threaded collar fits Fig. 1048 base

vision by reducing the amount of light wasted
outside of the visibility zone and not attracting as
many bugs.
LED: Sealed from the Environment
Retail Pkg.: Stealth series universal replacement lights are
designed to fit most other manufacturers’ bases. Fig. 1442
(Shown)
They feature two collars (one threaded and one
Locking Collar
locking), two screw positions, and an adjustable 0° Rake
head (wide 40°). Adjustability of the globe allows OEM Bulk Pkg.
for proper horizontal alignment regardless of base
configuration.
OEM Bulk Pkg.: These lights have fixed pole light heads with
either 0° or 5° pole rake and single locking or
threaded collar Fig. 1347
(Shown)
Adj. Head
Approx. Pole Catalog 2 Collars
Length Number Pole Rake, Collar, & Pkg. Type Retail Pkg.
24 1347DP2CHR
36 1347DP4CHR Pole Rake: Adjustable
42 1347DP5CHR Collar: Locking & Threaded
48 1347DP6CHR Package Type: Retail
54 1347DP7CHR
24 1442002CHR
30 1442003CHR
36 1442004CHR Pole Rake: 0° Compatible Bases (2-Pin)
42 1442005CHR Collar: Locking
48 1442006CHR Package Type: OEM Bulk
54 1442007CHR
60 1442008CHR
24 1447002CHR
30 1447003CHR
36 1447004CHR Pole Rake: 5° Fig. 1045 Fig. 1047 Fig. 1059
42 1447005CHR Collar: Locking 0° Rake 0° Rake 16° Rake
48 1447006CHR Package Type: OEM Bulk
54 1447007CHR
60 1447008CHR

36 1624004CHR
42 1624005CHR Pole Rake: 5°
48 1624006CHR Collar: Threaded
54 1624007CHR Package Type: OEM Bulk Fig. 1046 Fig. 1060 Fig. 1048
60 1624008CHR 5° Rake 5° Rake 5° Rake

Spare Parts Information
Bases Sold Separately - See Pages 58 & 59.
L.E.D.’s have no user serviceable parts

44 Visit www.perko.com for installation instructions and technical drawings on most PERKO products.
®
