Fold-Down Adjustable Replacement Bases

Fig. 1052 Fig. 1054
Fold-Down Adjustable Mount Bases Horizontal Vertical
Material: Zinc Alloy & Polymer or All Polymer
Finish: Chrome Plated or Black
Screw Size: #8
Base Dimension: Horizontal Mt.: 2” x 1-1/2” 2
Vertical Mt.: 2-1/4” x 5/8”
Features: Complete with knob, end plug, and adapter
for “V” or flat mounting surfaces.
Heavy Duty: • Chrome plated zinc alloy base 30° graduated adjustment
increments.
Fig. 1052A Navigation Lights
• For poles less than 48” long.
Horizontal Fig. 1054A
• Consult factory for ordering details.
Vertical
Figs. 1052/1054: Does NOT contain notch for through base wiring.
Fig. 1052 Fits Figs. 1134 & 1634
Fig. 1054 Fits Figs. 1137 & 1637
Figs. 1052A/1054A: Contains notch for through base wiring.
Fig. 1052A Fits Figs. 1181 & 1281
Fig. 1054A Fits Figs. 1184 & 1284
Standard Duty: • All black base with 0° to 180° adjustment.
• For poles less than 18” long. Notch Notch
Figs. 1052B/1054B: Contains notch for through base wiring.
Universal mounting bases - fits all fold down series poles.
Fig. 1052B
Horizontal

Quick Release Fold-Down Adjustable Mount Base
Features: • Fits Figs. 1138, 1638, & 1642
• Quick adjust handle (with 30° graduated adjustment
increments) allows pole light to fold down 90° in either
direction along the plane of attachment plate of the mount.
• Ideal for use on pontoon boat square rails or any flat
mounting surface. Notch
• For poles less than 48” long Fig. 1054B
Vertical

Through
Base Wiring Finish Mount Retail Pkg.
Heavy Duty
No Chrome Horiz. 1052DP0CHR
No Chrome Vertical 1054DP0CHR
Yes Chrome Horiz. 1052DPACHR
Yes Chrome Vertical 1054DPACHR Fig. 1058
Standard Duty Quick Release
Yes Black Horiz. 1052DPBBLK Vertical
Yes Black Vertical 1054DPBBLK
Quick Release Handle
No Chrome Vertical 1058DP0CHR*

Spare knob for zinc alloy bases: 1144A00BLK.
* Refers to Prop65 Warning

®
