FRENSCH
RESOL U X 871 / 872 / 873
Key Features & Benefits
O
• Surface mount with 270 rotation
• Integrated 10-30VDC drive electronics
• Integrated push-button dimming
• Illuminated dimmer switch is easily located in the dark
• No radiated heat – safe to touch
LED Colors
Single Color: Warm
871
Specifications 871 872 873
Beam angle (FWHM) 58 O
Power consumption 3W 6W 9W
Luminous flux (lm) 200 400 600 872
Lifetime hours (70% light output) 50,000
Halogen equivalency 20W 40W 60W
Input voltage 10-30VDC
Ingress protection (IP) IP40
Finishes 873
•
White B
A
E
C D
Dimensions 871 872 873
A Length 9.41" 239mm 16.9" 429mm 24." 619mm
B Hole Spacing 0.14" 3.43mm 0.14" 3.43mm 0.14" 3.43mm
C Width 0.98" 25mm 0.98" 25mm 0.98" 25mm
D End Cap Width 1.22" 3.10mm 1.22" 31.10mm 1.22" 31.10mm
E Height 1.35" 34.30mm 1.35" 34.30mm 1.35" 34.30mm
