FRENSCH

F-30

Key Features & Benefits
• LED replacement for Resolux 700 Series fluorescent
• A+ Energy Efficiency Rating (EU-Directive 87412012)
• Dimming compatibility with most halogen PWM digital dimmers
• Rear or surface-mount cabling
• Wide beam illumination
• UV stable PC lens will not yellow over time
• Maintenance free: no bulbs to change or store

LED Colors
Single Color: Warm, Cool

F-30
F-30.1 F-30.2 F-30.3 F-30.4
Specifications

Beam angle (FWHM) 108 O
24W
Power consumption 8W 16W 4.7W 32W
Luminous flux (lm)* 600 1300 1800 2600
Lifetime hours (70% light output) 50,000

Halogen equivalency 65W 130W 195W 260W
Input voltage 12VDC or 24VDC
Ingress protection (IP) IP40

* Luminous flux figures are for cool white only. Other figures are available on our website.
Finishes
•
White

A

B

F-30 Series
is compatible with our
DMS Series dimmers C
(pg. 57)
D

Dimensions F-30.1 F-30.2 F-30.3 F-30.4
A Length 15.12" 384mm 26.53" 674mm 37.95" 964mm 49.37" 1254mm
B Width 3.35" 85mm 3.35" 85mm 3.35" 85mm 3.35" 85mm
C Height 0.87" 22mm 0.87" 22mm 0.87" 22mm 0.87" 22mm
