Page 186 - Lewis

Hatches 185

Utility Hatches

500135

500155

500095
520505

FIG 5745 HATCHES

These saralon resin hatches are UV and water resistant with hidden fasteners, a 316 stainless steel hinge and the in-laid gasket
ensures a good seal. The door opens past 180°, it has larger inside dimensions and the cut out has a 3/8" clearance from start of
flange to beginning of screw hole.
No. Each I.D. O.D. Cutout Color
500091 $105.05 8-1/2"W x 12-1/2"L 11"W x 15"L 9-1/4"W x 13-1/4"L Sea Foam
500095 105.05 8-1/2"W x 12-1/2"L 11"W x 15"L 9-1/4"W x 13-1/4"L Polar White
500135 126.75 10-1/2"W x 14-13/32"L 13"W x 17"L 11-1/4"W x 15-1/4"L Polar White
500151 162.95 10-1/2"W x 20-1/2"L 13"W x 23"L 11-1/4"W x 21-1/4"L Sea Foam
500155 162.95 10-1/2"W x 20-1/2"L 13"W x 23"L 11-1/4"W x 21-1/4"L Polar White
520505 203.75 10-1/2"W x 27-1/2"L 13"W x 30"L 11-1/4"W x 28-1/4"L Polar White

Access Hatch Access Panels

FIG 8760
FIG 5746
These hatches feature integral cam-lock handles and
hinges recessed into a one-piece flange and a textured sur- These UV and water resistant saralon resin panels are impervi-
face. An O-ring in the beveled edge flange assures a ous to harsh chemicals, have hidden fasteners and removable
weathertight closure. lids for easy access.
No. Each I.D. O.D. No. Each I.D. O.D. Color
44230 $74.50 7"W x 11"L 10-3/4"W x 15"L 500171 $122.80 9-1/2"W x 13-1/2"L 12-1/4"W x 16"L Sea Foam
44430 132.50 9-1/2"W x 19-1/4"L 13"W x 23-1/4"L 500175 122.80 9-1/2"W x 13-1/2"L 12-1/4"W x 16"L Polar White
