Fuel Tank Senders Electric Fuel and Water Level Senders
Mechanical

35750

35722

35752

FIG 8383

Swingarm mechanical sending units with a direct site gauge or
with the conversion capsule gathers fuel level information with
the float. While accurate, the gauge will fluctuate as the fuel in
the tank "slosh" around. Swingarm electric sending units gath-
er fuel level information the same way as the mechanical send-
ing units. It does however connect to a dash mounted gauge
without a conversion capsule. Ohms resistance of 33-240 FIG 1286
Ohms. Available in sizes and styles to fit most any tank on the
market. Mechanical senders INCLUDE sight capsule 35759.
Electrical tank senders can be used with electric fuel gauges of Made of 316 stainless steel. Suitable for gas, diesel or water
35 to 240 Ohms — See Fig. 8377. Senders INCLUDE screws and with a SAE 5-hole pattern and resistance of 240-33 Ohms.
gasket. Tank hole diameter: 1-1/2". All senders are right handed. Measurement is done by series of reed switches positioned
No. Each Depth Description inside the level tube. A float with built-in magnets then trig-
35722 $39.25 6"-12" Electric gers the reed relays generating a potential free resistance with
35729 44.80 6"-24" Electric an Ohm value that increases or decreases. Volts: 12 or 24 DC.
35750 90.20 7-1/2" Mechanical No. Each Length
35751 91.05 8" Mechanical SSL8 $47.15 8"
35752 91.90 10" Mechanical SSL10 50.70 10"
35753 92.75 11-3/4" Mechanical SSL12 53.05 12"
35754 93.60 12-3/4" Mechanical SSL16 56.70 16"
35755 94.45 14" Mechanical SSL20 63.50 20"
35756 95.30 16-1/4" Mechanical SSL24 72.70 24"
35757 96.15 17-3/4" Mechanical SSL28 83.05 28"
35758 97.00 22" Mechanical SSL32 95.55 32"
For Gauges -— See Fig. 8378 SSL36 108.00 36" GAS TANK ACCESSORIES

Fuel Sender Gauges Universal Fuel Tank Sending Unit
Sight Capsule

35759

35760

FIG 7711
FIG 8378
Registers 240-30 Ohms (240 in empty position). Adjustable for
35759 mounts on any mechanical tank sending unit. 35760 4"-24" tanks, left or right arm. Gasket INCLUDED. Can be used
converts fuel level reading from standard direct site gauge to with Stewart Warner gauges.
electric dash mounted gauge (33-240 Ohms). No. Each Description
No. Each Type 90424P $56.85 Fuel Tank Sending Unit
35759 $23.85 Mechanical 64082 3.70 Spare Gasket
35760 93.00 Electric WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
