360 Water System Pumps

Ultra-Max Low-Profile Automatic Multi-Outlet Water Pressure System

FIG 9979

The system has a low-mounting profile, can be installed in any position and has vibration and noise isolating rubber mounts and
snap-in port fittings on a corrosion-proof base. Features a PAR-MAX 4 pump which self-primes to 5 feet, runs dry without damage
and provides quiet, low Amp draw operation. The 1-liter accumulator tank smoothes flow, eliminates pulsation, and ensures even
temperature mix at the faucet. Its bladder type design never needs recharging. Pumpgard strainer snaps directly into the PAR-MAX
pump and is supported by a sturdy molded in leg. INCLUDES: 1/2" Qest threaded and 1/2" barbed inlet and outlet ports. Ignition-
Protected. Weighs 15 lbs.
Amp Draw
No. Each Volts GPM at 10 PSI Cut In Cut Out
59451-1012 $445.50 12 3.8 6 20 PSI 40 PSI
For Additional Hose Barbs — See Fig. 116
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
VFLO Water Pressure Pump Par-Max Plus Water System Pumps
6 GPM – 5-Chamber Diaphragm

WATER SYSTEM PUMPS

FIG 3842

These VFLO variable flow, constant pressure 4-chamber posi- FIG 7630
tive displacement diaphragm water pumps now feature
DiMOND technology designed to automatically diagnose and
monitor all aspects of your pump's performance to prevent The high pressure capability of the new pumps provides
system failure. VFLO is powered by a new variable speed drive exceptional flow and consistent water pressure to easily han-
that delivers the exact amount of water flow needed to per- dle the demand of multiple outlets. All models include soft
form a variety of onboard delivery tasks. Since the pump is rubber mounts and quick connect fittings for ease of installa-
constantly monitoring water flow and electrical current, it tion. The co-injected molded diaphragm and larger heavier
automatically adjusts itself as needed, ensuring that your sys- duty motor brushes significantly extend pump life up to 50%
tems are operating at peak efficiency. INCLUDES 1/2" quick- longer than existing diaphragm pumps. It is self-priming up to
connect fittings. Ignition-Protected. 10 ft (3m) and can run dry without damage. Ignition-Protected.
No. Each Volts Ports GPM No. Each Volts Ports GPM
42755-0092 $418.80 12 DC 1/2" Snap-In 5 82600-0092 $254.15 12 DC 1/2" Snap-In 6
42755-0094 467.75 24 DC 1/2" Snap-In 5 82600-0094 273.20 24 DC 1/2" Snap-In 6
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
For Jabsco Parts — See Page 298-307
