424 Gasoline Filters

Racor Gasoline Filter/Separators

High performance Racor Spin-On Fuel Filter/Water Separators handle gasoline engine flow rates from 15 to 90 GPH. For outboard engines, a
rugged reusable clear see-through bowl lets you visaully monitor filter effectiveness. The see-through bowl resists discoloration from additives and ultra-
violet light. Inboard engines require a metal bowl to be UL recognized and to meet USCG requirements. Metal bowls can be used for outboards as well.
110A & 660 series offer multi-port heads which allow easy installation anywhere in the engine compartment. All units must be installed on the suc-
tion (vacuum) side of the fuel or transfer pump; however, a maximum head pressure of 15 PSI is permissible. (110A is not recommended for pressure
side installations above 150 PSI.) All come with drains, plugs and "O" Rings. All are 10 micron.

01 – Shown
110A 120RRAC01/02 320RRAC01 320RRAC02 490RRAC01 660RRAC01 3120RRAC32
(35 GPH) (30 GPH) (60 GPH) (60 GPH) (90 GPH) (90 GPH) (120 GPH)
SPECIFICATIONS
110A
MODELS Gas Diesel 120RRAC01/02 320RRAC01 320RRAC02 490RRAC01 660RRAC01 3120RRAC32
}
Maximum GPH 35 15 30 60 60 90 90 120
Flow Rate LPH 132 57 114 227 227 341 341 456
Filter Element R11T *S3240 S3227 S3228TUL S3227 S3232 S3232TUL
Application In/Outboards In/Outboards Outboards In/Outboards Outboards Outboards In/Outboards
Bowl Metal UL RK21364 RK10109 N/A RK30473-02 N/A N/A RK21430
Clear N/A RK10222 RK30475 N/A RK30475 RK30475 N/A
Port Size, NPT 1/4"-18 1/4"-18 1/4"-18 1/4"-18 3/8"-18 3/8"-18 1/2"-14
Number of Ports 4 4 3 3 4 5 2
Height Inches 6" 6.5" 9.3" 9" 9.9" 11" 10.4"
Width Inches 3.2" 3.2" 4" 4" 4.5" 4.2" 4"
Diameter Inches 3.3" 3.2" 4" 4" 4.8" 4.5" 5"
Weight Lbs. 1.3 1.1 2.3 2.4 2.6 2.5 6
All inboard gasoline-powered engines require a metal bowl to meet USCG requirements.
* Filter element for No. 120RRAC02 is S3240TUL – SPECIAL ORDER
Racor Gasoline Spin-On Series Fuel Filter Water Separators
GASOLINE FILTERS No. $175.55 GPH U.L. Case No. $254.25 GPH U.L. Case
Fittings are sold separately.
FIG 1RAC

Each
Each
NO
3120RRAC32
35
120
6
YES
6
110A
490RRAC01*
NO
164.85
115.60
12
NO
90
6
30
120RRAC01
6
660RRAC01
90
12
NO
167.00
169.95
YES
120RRAC02
30
12
60
NO
320RRAC01
121.10
* INCLUDES Primer Pump
149.05
320RRAC02
12
60
YES
®
Racor Aquabloc Replacement Elements
FIG 4RAC
No. Each Microns Fits Series No. Each Microns Fits Series
R11T $25.65 10 110A S3232TUL $50.30 10 660RRAC02
S3227 36.40 10 320RRAC01 S3228SUL 39.00 2 320RRAC02
& 490RRAC01 S3228TUL 39.15 10 320RRAC02
S3232 47.20 10 660RRAC01 S3240 29.85 10 120RRAC01
Case Quantity – 12
