Thru-Hulls 445
Thru-Hull Connections Extra-Long Thru-Hull Connections
FIG 322b
Cast bronze – with lock nut.
No. Each I.P.S. Flange Diameter Length
1/2 $25.65 1/2" 1.70" 2-1/4"
3/4 29.95 3/4" 1.93" 2-1/4"
1 44.10 1" 2.31" 2-1/2" FIG 348
1-1/4 66.95 1-1/4" 2.81" 3"
1-1/2 86.05 1-1/2" 3.06" 3-1/4"
2 110.60 2" 3.26" 3-1/2" Cast bronze. Back side of flange is machined to fit snugly to
2-1/2 152.50 2-1/2" 4.31" 3-5/8" hull and is grooved to retain bedding compound or sealant.
3 324.80 3" 5.50" 4" Neck is threaded to approximately 3/8" from flange. Lock
4 615.00 4" 7.00" 5-1/4" nut INCLUDED.
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov Flange
No. Each I.P.S. Length Diameter
Flanged Nuts 3/4 $72.35 3/4" 5-1/2" 1-7/8"
1 77.80 1" 5-1/2" 2-1/4"
1-1/4 118.75 1-1/4" 5-1/2" 2-3/4"
1-1/2 129.65 1-1/2" 5-1/2" 3"
2 165.55 2" 5-1/2" 3-5/8"
FIG 75 2-1/2 211.35 2-1/2" 5-1/2" 4-1/2"
Plain cast bronze. Thru-Hull Connections for Hose
No. Each I.P.S.
4 $11.45 1/2"
5 12.10 3/4"
6 14.45 1"
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Low-Volume Thru-Hulls
FIG 2132
FIG 3833
These bronze thru-hull water pick-ups are for
low-volume pumps, like baitwell. They have
straight pipe threads on the neck and tapered Made of 316 stainless steel.
pipe threads at the end to mate with other fit- Hose Flange Thread
tings. They INCLUDE a flange jam nut and two No. 8 flathead No. Each Size Diameter Length
screws in the flange to hold the "scoop" in the correct position. 5/8 $29.00 5/8" 1-7/8" 1-1/8"
Flange Neck 3/4 36.30 3/4" 1-7/8" 1-1/8"
No. Each Size O.D. Length 1 36.25 1" 1-7/8" 1-3/16"
3/4 $30.80 3/4" 1-7/8" 2-1/4" 1-1/8 36.30 1-1/8" 2-3/8" 1-1/4"
1 46.15 1" 2-1/4" 2-1/2" 1-1/4 53.05 1-1/4" 2-3/8" 1-5/8"
1-1/4 105.95 1-1/4" 2-3/4" 3-1/4" 1-1/2 53.00 1-1/2" 2-3/8" 1-1/2"
2 86.90 2" 3-1/4" 2"
Thru-Hull Connections for Hose THRU-HULLS
Glass-Filled Nylon and Stainless Thru-Hull Connections for Hose
FIG 350B FIG 350C
FIG 2125
Bronze Cast bronze – machined flange. Chrome
Made of nylon 66 and 30% glass-filled body with a 316 stainless
steel face. No. Brz. Each Chr. Each Hose Size Max. Thk. Flange Diam.
No. Each A B C 5/8 $34.85 $49.00 5/8" 1-1/16" 2.00"
5/8 $9.70 1-7/8" 1-5/8" 1" 3/4 31.85 — 3/4" 1-5/8" 1.75"
3/4 9.70 1-7/8" 1-5/8" 1-1/8" 1 52.05 — 1" 1-3/4" 2.25"
1 11.05 1-7/8" 1-5/8" 1-3/16" 1-1/8 54.45 — 1-1/8" 1-3/4" 1.88"
1-1/8 11.30 2-3/8" 1-7/8" 1-1/4" 1-1/4 71.40 — 1-1/4" 1-7/8" 2.81"
1-1/4 12.60 2-3/8" 1-7/8" 1-5/8" 1-1/2 86.05 — 1-1/2" 1-7/8" 3.06"
1-1/2 15.50 2-3/8" 1-7/8" 1-1/2" 2 110.60 — 2" 1-7/8" 3.90"
2 22.95 3-1/4" 2-1/4" 2" WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
