448 Seacocks

Tri-Flanged Seacocks
Full-Flow FBV Series
FIG 9361

Patented field reversible handle allows you to select the closed position orientation (clockwise or counterclockwise)
that best suits the installation. It has a square hole to accept standard ratchet, to help reach valves in hard-to-reach
locations and ease actuation of difficult to operate valves. Full pipe-size flow. Triangular base with bolt pattern to
match most popular brands makes retrofit easy. Stainless steel handle and hardware, chrome plated brass ball,
teflon seats and seals and bonding attachment on base. Drain plugs on both sides for convenience of winterization.
No. Each Size Height Weight
3/4 $69.95 3/4 IPS 6.14" 1.86 lbs.
1 95.70 1" IPS 6.98" 2.58 lbs.
1-1/4 118.60 1-1/4" IPS 7.12" 3.04 lbs.
1-1/2 160.15 1-1/2" IPS 8.23" 4.36 lbs.
2 259.05 2" IPS 10.14" 6.16 lbs.
2-1/2 467.50 2-1/2" IPS 12.81" 14.3 lbs.
3 631.95 3" IPS 14.85" 23.2 lbs.

Groco Ball-Type Seacocks
Full-Flow BV Series

FIG 9457

Bronze valve body is flanged for a more secure installation. Stainless steel ball and stem with Teflon seats
and seals. Designed and manufactured with in-field serviceability in mind. Full pipe-size flow with all sizes;
no restrictions to reduce the flow of water through the valve. Your engines and other equipment will get the
full flow of water required for optimum operating efficiency. All sizes have patented, field reversible handle.
No. Each Female IPS Height Weight
3/4 $220.00 3/4" 5.9" 2.30 lbs.
1 260.00 1" 6.8" 3.50 lbs.
1-1/4 331.00 1-1/4" 7.1" 4.60 lbs.
1-1/2 378.00 1-1/2" 8.0" 6 lbs.
2 518.00 2" 8.2" 10 lbs.
2-1/2 806.00 2-1/2" 10.0" 16 lbs.
3 1150.00 3" 10.5" 28 lbs.
4 2708.00 4" 19.5" 58 lbs.
RHK2 179.80 Replacement Handle Kit – BV2500
RHK3 211.00 Replacement Handle Kit – BV3000
5" Available on Special Order

Apollo Ball-Type Seacocks
Full-Flow
Made in
FIG 4556 USA
Nos. 3/4
thru 3 The bronze ball is hard-chromed and sealed in teflon rings. The triangular flange is pre-drilled to accept
SEACOCKS turn on and 1/4 turn off and is clearly marked. Each of these seacocks is tested to 400 P.S.I. 2.70 lbs.
three screws or bolts, NOT included. A drain plug is installed. Vinyl-coated stainless steel handle rotates 1/4
Spare
Female
Spare
Each
Handle
IPS
Weight
Nut
No.
3/4
2H
3/4"
7/16"-20
$150.55
1
1"
239.40
7/16"-20
3H
1-1/4
5.75 lbs.
3H
7.25 lbs.
1-1/2"
7/16"-20
342.45
1-1/2 222.55 3H 7/16"-20 1-1/4" 3.80 lbs.
2 648.65 4H 7/16"-20 2" 12.90 lbs.
2-1/2 954.95 4H 7/16"-20 2-1/2" 18.20 lbs.
3 1598.95 4H 1/2"-20 3" 32.00 lbs.
For Spare Handles and Nuts — See Fig. 6625
Flanged Seacock Backing Block
Seacock
Not Included FIG 9451
BB Series Flanged Seacock installation is improved with the use of a backing block between the valve flange
and the hull. Each size fits multiple seacock sizes. Press threaded inserts into the hull side of the backing block
into the holes that match the seacock flange. 1/2" thickness is rigid enough for a secure installation but flexible
enough to conform to minor hull curvature. Will not swell or absorb moisture.
Accepts Threaded
No. Each Seacock Size Diameter Inserts
BB1 $52.85 3/4" to 1" 4.29" 5/16"-18
BB2 62.75 1-1/4 to 1-1/2" 5.38" 5/16"-18
BB3 74.00 2" to 2-1/2" 7.13" 3/8"-16
