Thru-Hulls 447

Thru-Hull Connections Thru-Hull Connections
Meet and exceed the
Meet and exceed ABYC H-27 and ISO
the ABYC H-27 9093-2 Standards
and ISO 9093-2
Standards FIG 8880
Molded in high-strength glass-rein-
forced Marelon. Corrosion and elec-
FIG 8879 trolysis resistant, for use above or below the waterline. Must
be installed with proper bedding compound. Has hose barb
tailpiece with mushroom head.
Molded in high strength glass-reinforced Marelon. Corrosion Flange Thread
and electrolysis-resistant, for use above or below the water- No. Each Hose Diam. Length
line. Must be installed with proper bedding compound. Fully 906022 $18.90 1/2" 1-1/2" 1-3/8"
threaded with mushroom head. 906024 20.45 3/4" 2-1/8" 1-1/2"
Flange Thread 906026 23.45 1" 2-3/8" 1-1/2"
No. Each I.P.S. Diam. Length 906028 28.45 1-1/4" 2-5/8" 1-3/4"
906010 $18.90 1/2" 1-1/2" 1-1/2" 906030 34.95 1-1/2" 3" 1-3/4"
906012 20.45 3/4" 2-1/8" 1-3/4" 906032 43.45 2" 3-1/2" 1-1/4"
906014 23.45 1" 2-3/8" 2-1/4"
906016 26.95 1-1/4" 2-5/8" 2-3/4" Flush Thru-Hull Connections
906018 34.95 1-1/2" 3" 2-3/4" Meet and exceed the
906020 46.90 2" 3-1/2" 2-1/2" ABYC H-27 and ISO
9093-2 Standards
Thru-Hull Connections
Molded White Plastic FIG 9620

Precision molded in high-strength
glass-reinforced Marelon ® . Ideal thru-
hulls for use above or below the waterline. Must be installed
with proper bedding compound. 53° angle on the flush head.
Flange Thread
No. Each IPS Diameter Length
FIG 328b 1/2 $17.45 1/2" 2-3/8" 2"
3/4 18.90 3/4" 2-7/16" 2-1/4"
1 18.90 1" 2-27/32" 2-3/8"
These thru-hull connections are especially suitable for installa- 1-1/4 22.45 1-1/4" 2-13/16" 3"
tion in metallic hulls where electrolysis is a serious factor. Can 1-1/2 34.95 1-1/2" 2-13/16" 3"
be painted or machined. Thru-hull connections for use with
hose, are NOT recommended for use below the water line.
Hose Flange Thru-Hull Fitting Installation Tool
No. Each Size Diam. Length Pkg. FIG 9968
4 $6.85 1/2" 1-1/2" 3-1/8" 10
4A 6.85 5/8" 1-1/2" 3-1/8" 10
5 6.50 3/4" 1-7/8" 3-1/2" 10 Slide the thru-hull fitting, flanged end first, over the
6 8.25 1" 2-1/4" 4-1/8" 10 tool. It will stop at the proper step and engage with
6A 9.75 1-1/8" 2-1/4" 4-1/8" 10 the notches on the tool. A length of monofilament,
8 12.90 1-1/2" 3" 4-1/8" 10 tied to the eye, is then placed into the already-cut
Fig. 4665 No. 72 53.65 2" 4" 5" 1 hole in the hull of the boat. With the fitting pulled
firmly against the hull of the boat, the locknut or
the seacock may be screwed onto the fitting. NOT THRU-HULLS
Teak Thru-Hull Plugs for removing old thru-hulls.
No. Each Description Fits Size
530 $83.40 Installation Tool 1/2" to 3"

Sta Plug
FIG 6071
FIG 3616
No. Each Length Taper
60148 $5.05 4" 7/8" to 7/16" This is a soft, cone shaped plug
60149 9.75 6" 1-1/2" to 11/16" designed to conform to the irregular
and unpredictable shapes of a hull
Wooden Thru-Hull Plugs breach. Adapts to slow or stop the
leak. Unlike old fashion wooden
plugs, its unique shape allows it to
FIG 3613 be compressed by hand or cut to fit.
It also gets into hard-to-reach loca-
tions and can also be pushed into a
Assortment of nine conical wood plugs for gap using a screwdriver or similar
stopping emergency leaks in hulls, decks tool. Usable 10° to 275°F. NOT for
and thru-hulls. fuel leaks.
No. Pack of 9 Length/Taper No. Each Description
10103 $35.35 4-3/8" L x 3/4" to 2" Diam. 150110 $23.50 5" Diam. x 9" Long
