ACCESSORIES FOR WASTE WATER TANKS
Angled fittings
Synthetic fittings for VETUS flexible tanks (type FT) or rigid tanks (type RT). Suitable for hoses with an internal diameter
of Ø /2” (13 mm), /8” (16 mm), /4” (19 mm), 1” (25 mm) or 1 /2” (38 mm).. The required hole size for flexible tank is Ø1 /8” (42 mm)
3
5
1
1
5
11
and for rigid tanks Ø1 /16” (43 mm).

RT FT

Hose Ø Hose Ø
Type Angle Type Angle
inches (mm) inches (mm)
RT13B 1/ 2 (13) right angle FT13B 1/ 2 (13) right angle
RT16B 5 /8 (16) right angle FT16B 5 /8 (16) right angle
RT19B 3 /4 (19) right angle FT19B 3 /4 (19) right angle
RT25B 1 (25) right angle FT25B 1 (25) right angle
RT38B 1 /2 (38) right angle FT38B 1 /2 (38) right angle
1
1

Installation kit type BTKIT

Consisting of 1 inspection lid with counter-flange and
fastenings, 2 securing straps, and 1 wrench for angled fittings.
Specifications
• Overall diameter Ø 6 /64” (156 mm)
6
• Cut out diameter Ø 4 /32 (115 mm)
17

Type Description
BTKIT Fitting kit for synthetic waste water tanks
BTKIT

Lockable ball valve type BV1½L
This stainless steel (AISI 316) ball valve with G1½ thread is in some countries a
legal requirement to prevent the accidental discharge of black water in port.
This valve can be padlocked (padlock itself is not supplied).
BV1 /2L
1

Type Description
BV1 /2L Stainless steel (AISI 316) ball valve
1

164 Waste water systems - Want to know more? Visit www.vetus.com
