ACCESSORIES FOR WASTE WATER TANKS

Synthetic hose adapters type HA
These synthetic hose adapters can be cut to the appropriate
hose sizes.

Type Ø Dim. inches (mm)
1
HA1338 1 /2 - 1 /2 (13 - 38)
HA3060 1 /16 - 2 /64 (30 - 60)
3
23
HA3060
HA1338

Universal inspection port for tanks type ILT120

Innovative inspection port with robust design
The standard delivery of the VETUS ILT is an innovative port with flange-in-ring design
which facilitates easy opening, inspecting and cleaning the tank, even after being closed
for a long time. The inspection port has a counter flange and a rubber seal which are
inserted into a Ø 6 /4” (159 mm) hole in the tank. All that needs to be done is tighten the
1
4 supplied bolts which compresses the rubber seal to ensure perfect sealing.
The “clamp and seal” design simplifies installation, making the drilling of a
Ø 6 /4” (159 mm) hole the hardest part in the installation! ILT120
1
The black blind plate can be replaced by various connection kits.

Waste water connection kit ILTCONW
Although not mandatory as with fuel tanks, a large inspection port in a waste water
tank will facilitate cleaning. Having all the connections at a single point also makes
inspection simpler. The VETUS waste water disc is supplied with everything you need
for your waste water tank, it doesn’t matter if it’s a custom made steel, aluminium or a
VETUS thick walled rigid tank.
Connections that come with this interchangeable disc are
• Ø 1 /2”(38 mm) connection for discharge (ability to make this a suction connector by
1
mounting a standard Ø 1 /16” (40 mm) PVC pipe)
9
1
• Ø 1 /2”(38 mm) inlet connection
• Ø 1”(25 mm) inlet connection
3
• Ø /4”(19 mm) inlet connection
• Ventilation connection Ø /4”(19 mm)
3
• 5 hole SAE flange tank level sensor connection (suitable for SENSORA, SENSORB
and WWSENSORA)
ILTCONW
Diameter Diameter hole
Type Description
inches (mm) inches (mm)
ILT120 Inspection port with counter flange 43/4“ (120) 61/4 (159)
VSAW159 Ø 61/4“ hole saw for plastic, G.R.P. or 61/4 (159)
metal tanks
