ACCESSORIES FOR WASTE WATER TANKS

Ultrasonic level sensor type SENSORA
Easy measurement SENSORA
This VETUS ultrasonic level sensor is contactless and will easily measure
the fluid level in the tank.
For more information and available level
Type Description sensors see page 109.
SENSORA Ultrasonic level sensor

Waste water control panel type WWCP
Integrated tank level monitoring
This easy-to-use control panel with security lock can be used manually or automatically to control the full tank pump-out
and manage the complete waste water system. The WWCP panel is connected to a VETUS level sensor (type WSENSORA or
SENSORA) and indicates the content level in the tank using LED’s it will ignore brief maximum level peaks caused by boat
movements. A motorised ball valve can also be connected to the panel. In either manual or
automatic mode, the valve will open before the pump starts. Once the tank is empty, the pump
will switch off and the valve will close automatically. A switched outlet on the panel, connected
to a relay in the toilet power supply, makes it possible to prevent the toilet(s) from being
flushed if the tank is full.
Specifications
• Panel dimensions 3 /8” x 3 /8” (85 x 85 mm)
3
3
• Build-in depth 1 /16” (40 mm)
9
• Suitable for 12 or 24 Volt
• Usage in stand-by mode 4mA, electric pump 10A max,
remotely controlled ball valve 5A max and external alarm 1A max.
• Valve and level sensor are not included
Type Description WWCP
WWCP Waste water control panel

Vacuum operated vent valve type VRF

Indispensable safety factor
To prevent the possibility of insufficient air entering through the vent line during pump
out operations causing the tank to implode, VETUS has developed a valve according to the
ISO8099 standard. In case of significantly reduced pressure in the holding tanks, the valve
will open automatically to let air into the tank. By using this valve fitting of a large diameter
vent line is no longer necessary. The valve is made from synthetic materials and therefore
absolutely corrosion-free. Hole size in the tank is 2 /64” (56 mm).
13
Type Description VRF56A
VRF56A Vacuum valve for waste water tank

Waste water / bilge pump type EMP140
360º Rotating hose connections, less installation time
This reliable pump with a capacity of 27 l/min at zero head, is self-priming, provided with 2 duck-bill valves and suitable for
pumping grey and black water. It has rotating hose
connections so installation time will be reduced.
Specifications
• Weight 14.4 lbs (7kg)
• Max suction height 10 ft. (3 mtr)
• Max delivery height 6 ft. (5 mtr)
• Available in 12 or 24 Volt
• Current at 12 Volt 6A and at 24 Volt 4A

Hose connection
Type Volt
inches (mm)
EMP14012B 12 1 /2 (38)
1
EMP14024B 24 1 /2 (38)
1
EMP140
