The VW Series of anchor winches are designed
for traditional rope and chain combination anchor
rodes, where manual transfer of the rode from the
rope warping drum to the chainwheel is required.

Features and benefits
• Provides the versatility of operating two anchors from one
winch
• Functional rope hauling from any direction using independent
MAX-grip™ snag-free warping drum with clutch
disengagement of chainwheel for positive control of all ropes
• Permits use of traditional shackle and thimble rope and chain
connection
• Allows alternative mounting horizontally on a fore and aft
bulkhead inside chain locker for below deck installation
• High-quality finish on above deck components, manufactured
from marine grade stainless steel (AISI 316) and chromed
bronze, for long term durability
• Cone type brake/clutch mechanism permits manual ‘Free Fall’
anchoring. Cone clutches, unlike dog clutches, provide smooth
progressive engagement ensuring safe operator control
• Chainwheel locking pawl (except on VW500 and VW10)
VW10 Capstan Version
• Simplified through deck installation by modular design and
precise alignment of gearbox to the topworks utilising
marine-grade stainless steel (AISI 316) bolts
• Anodized aluminium gearbox and spacertube
• Heavy duty, dual direction motor, designed for marine winches
• Easily disassembled for servicing

VW10 WINDLASS FOR USE WITH SPLICED ROPE/CHAIN STANDARD EQUIPMENT REQUIRED
The VW10 evolved from the demand for a vertical windlass that could be used in a FOR SINGLE DIRECTION CONTROL
horizontally installed configuration (refer image above), but which would also, Dual Direction Solenoid (included)
interactively handle a rope/chain rode. The chainwheels on traditional VW models could Emergency crank handle/clutch control lever (included, except with VW500)
be used with chain only rodes. The VW10, capable of automatically handling up to Chainwheel to suit chain specified chain size (included)
10 mm (3/8”) chain and 16 mm (5/8”) rope, is ideally suited for use in sailing boat Circuit breaker/isolator panel (not included)
anchor lockers, where space considerations are critical. Quick and easy to install Windlass electrical controls (not included)
and available with or without independent warping capstan, the VW10 is destined to OPTIONS
become an instant hit in this unique niche market. 1. AutoAnchor™ Equipment 5. Extra deck clearance kit
2. Foot Switches 6. Hydraulic motor (except on 500)
3. Chain Stopper* 7. Up/Down remote control panel
4. Chain Snubber 8. Circuit breaker/isolator panel
All standard and optional control accessories can be found on
pages 330 - 333.
