Silicone Hose and Couplers 731

Mylar Finish Shiny Blue Silicone Hose
Coolant and Exhaust
For short runs only
Wet exhaust only
FIG 9697 Example: Diameter of hose x 2

This hose is made of fume and chemical resistant premium silicone rubber, reinforced with 3-ply woven polyester fabric. The outer
layer of silicone resists the effects of oil splash, temperature extremes, vibration and age hardening. Stays flexible and outlasts ordi-
nary hose by years. Temperature range: -67°F to +347°F. Meets SAE J2006 Class A. Smooth band hose clamps are recommended:
Fig. 9696 Constant-Torque or Fig. 3191 Aero-Seal. Recheck torque after installing while engine is still cold. Torque to 20-30 in. lbs.
MINIMUM BILLING – 1 FOOT
I.D./ Fig. 9696 I.D./ Fig. 9696
No. Per Foot O.D. Hose Clamp No. Per Foot O.D. Hose Clamp
1/2 $7.25 15/16" CT10L 2-1/2 $26.75 2-15/16" CT300L
5/8 8.15 1-1/6" CT16L 2-5/8 27.20 3-1/16" CT350L
3/4 9.15 1-3/16" CT16L 2-3/4 29.35 3-3/16" CT350L
7/8 10.40 1-5/16" CT16L 3 31.95 3-7/16" CT350L
1 11.15 1-7/16" CT16L 3-1/4 32.20 3-11/16" CT400L
1-1/8 13.80 1-9/16" CT24L 3-1/2 37.15 3-15/16" CT400L
1-1/4 14.75 1-11/16" CT24L 4 42.60 4-7/16" CT450L
1-3/8 17.90 1-13/16" CT200L 4-1/2 47.55 4-7/8" CT500L
1-1/2 16.35 1-15/16" CT200L 5 52.45 5-3/8" CT550L
1-5/8 17.60 2-1/16" CT250L PER LENGTH
1-3/4 18.95 2-3/16" CT250L 6 201.25 6-1/2" CT700L
2 21.55 2-7/16" CT300L 8 267.10 8-1/2" CT900L
2-1/8 22.85 2-9/16" CT300L 10 330.10 10-1/2" Fig. 9699 No. 10
2-1/4 25.35 2-11/16" CT300L
2-3/8 26.25 2-13/16" CT300L
1/2"-5" Standard Length – 12 Feet 6"-10" Standard Length – 3 Feet
Silicone Single/Double Blue Nautiflex Corrugated Silicone Exhaust Hose
Hump Couplers

FIG 9700b

Blue silicone tube and cover with smooth finish for easy clean up. Wire reinforced;
will not collapse under suction or in a bend. Corrugated cover is easy to bend for
easy installation. Two-ply construction consists of wire captured between fabric
Single
piles. Stable at elevated temperatures. Resistant to exhaust fumes, ozone, mild
chemicals, anti-freeze, and salt water. Temperature range: -20° to +350°. Series 262.
MINIMUM BILLING – 1 FOOT
I.D./No. Per Foot O.D. Hose Clamps
Double
3/4 $31.05 1-3/8" 12H
1 34.30 1-27/64" 20H
FIG 4808 1-1/4 38.70 1-45/64" 24H
1-1/2 54.20 2" 28H
1-5/8 51.95 2-11/64" 32H
Premium blue exhaust hose designed for main 1-3/4 57.10 2-19/64" 36H
engine wet exhaust pipe connections. Designed 2 60.15 2-17/32" 36H
to relieve angular and longitudinal vibration in 2-3/8 63.75 2-7/8" 40H SILICONE HOSE AND COUPLERS
marine wet exhaust systems. Will correct 2-1/2 69.95 3-3/64" 44H
slightly offset pipes. Resists temperatures up to 2-7/8 74.65 3-7/16" 56H
350°F. Coupler length: 14". No. 4 is 6" long. 3 86.05 3-35/64" 52H
I.D./No. Each O.D. Description 4 125.25 4-49/64" 80H
4 $47.65 4-5/16" Single-Hump Coupler 5 144.05 5-3/4" 88H
6 140.05 6-3/8" Double-Hump Coupler 6 201.95 6-15/16" 128H
8 186.25 8-3/8" Double-Hump Coupler Standard Length – 12-1/2 feet
10 247.60 10-3/8" Double-Hump Coupler 5" and 6" Standard Length – 10 feet
Mylar Finish Shiny Blue Silicone Heater Hose
FIG 9698

This blue silicone hose is made of the same fine quality silicone compounds as in Fig. 9697. It's a lighter duty construction made
with 1-ply of braided polyester fabric. It has excellent resistance to hardening and shrinking and is unaffected by ozone and meets
SAE J20R3 Class A requirements. Smooth band clamps are recommended such as our Fig. 9696 Constant-Torque or Fig. 7714 Torro
Series. Re-check torque after installing while engine is cold. Torque to 20-30 in. lbs.
MINIMUM BILLING – 1 FOOT
I.D./ I.D./
No. Per Foot O.D. Hose Clamp No. Per Foot O.D. Hose Clamp
1/4 $3.10 37/64" Fig. 7714 6 5/8 $5.95 61/64" Fig. 9696 CT10L
3/8 4.75 45/64" Fig. 7714 10 3/4 6.85 1-1/8" Fig. 9696 CT16L
1/2 5.30 53/64" Fig. 9696 CT10L 1 8.50 1-3/8" Fig. 9696 CT24L
Standard Length – 50-Foot Roll
