734 Bilge and Sanitation Hoses

Black Bilge and Livewell Hose Sanitation, Vacuum or Bilge Hose

FIG 1985b FIG 1984b

Series 149 – Specially made hose designed expressly for criti- Series 148 – All sizes are white except the 2" which is clear,
cal livewell connections. Smooth-walled, all vinyl hose can be multi-purpose, extra-heavy smooth-walled, all-vinyl hose for
connected below the water line. For live well intake and drain. sanitation system connections (head intake, head to holding
Also excellent for bilge pump discharge and drain lines. Special tank, holding tank discharge and pump out). Excellent for criti-
vinyl compound allows excellent flexibility and tight bend radii. cal bilge, drain, scupper line and potable water fill applications.
Smooth cover permits easy clamping without use of hose Formulated with FDA approved and low-water absorption com-
cuffs. Hose resists bilge chemicals and abrasion. Can be easily pounds that give excellent resistance to odor permeation and
pulled through bulkheads, no corrugations to catch or tear. toilet chemicals. Reinforced with hard vinyl helix for good bend
MINIMUM BILLING – 1 FOOT radius, vacuum rating and corrosion protection. Temperature
Per VAC Hose Bend range: 13° to 158°F. The use of double clamps and sealing com-
No./I.D. Foot O.D. Rating Clamps** Radius pound is recommended for below water line connections.
5/8 $3.25 7/8" 28 8H 3" MINIMUM BILLING – 1 FOOT
3/4 3.65 1" 28 10H 3" Per VAC at 68°F Bend Hose
1 4.40 1-1/4" 28 16H 3" No./I.D. Foot O.D. Rating Radius Clamps** Color
1-1/8 4.80 1-3/8" 28 16H 4" 3/4 $3.70 1" 28 3" 10H White
1-1/4 6.20 1-9/16" 28 20H 4" 1 4.40 1-1/4" 28 3" 16H White
1-1/2 6.65 1-7-8" 28 24H 5" 1-1/8 4.60 1-3/8" 28 4" 16H White
Standard Length – 50 ft. Roll Out Carton 1-1/4 5.70 1-9/16" 28 4" 20H White
1-1/2 6.05 1-7/8" 28 5" 24H White
Odor-Resistant Black Sanitation Hose 2 7.40 2-1/2" 28 5" 32H Clear
Standard Length – 3/4"-1-1/2" 50 ft. Roll Out Carton
Very Flexible with Green Stripe
Standard Length – 2" 100 ft. Roll
For Hose Fittings — See Fig. 9771
Super PVC Sanitation Hose
Series 144

FIG 6561b

BILGE AND SANITATION HOSES
Series 101 – A formulated rubber compound made especially
for toilet application. The tube and cover eliminates the sanita- FIG 1982
tion system's biggest problem: odor. It is very flexible. 2-ply
hose with a wire, for tough reinforced construction. Has green
embossed letters. The use of double clamps and sealing com- Smooth walled PVC compound specially formulated to offer
pound is recommended for below water line connections. superior resistance to odor permeation. Reinforced with a
Per Hose Bursting rigid vinyl helix to prevent collapsing in bends and under vacu-
No./I.D. Foot O.D. Clamps** Pressure Lbs. um. Smooth cover permits clamping without cuffs. Not for
1-1/2 $17.45 1-55/64" 28H 150 potable water. Color: White.
Standard Length – 12-1/2 Feet MINIMUM BILLING – FOOT
For Hose Fittings — See Fig. 9771 Per Vac Bend Hose Std.
No./I.D. Foot O.D. Rating Radius Clamp Lgth.
1" $6.80 1-1/4" 28 3" 12H 50 ft.
Tigerflex Cream Color Sanitary Hose 1-1/2" 9.30 1-3/4" 28 5" 24H 50 ft.
Sanitation Hose Fittings

FIG 9116b M915
FS15 MS15
PVC Marine Sanitary Hose is designed with a twist cover for FIG 9771
required flexibility in confined bilge area. Smooth bore allows
for unrestricted flow. Left hand end cuffs recommended. Great
for marine bilge discharge, toilet transfer, and dock side pump Fiberglass-reinforced nylon fittings designed to fit Series 101
out lines. Not for potable water. EASY TO BEND AROUND and 148 hoses without heating or special tools. For use in san-
SHARP CORNERS. Use with hose cuffs below. itation systems, deck drain systems and water tank fill.
MINIMUM BILLING – 1 FOOT No. Each Style Hose I.D. Thread
No./I.D. Per Foot O.D. Pressure @ 68°F FS15 $15.20 Straight Female 1-1/2" 1-1/2" Female IPS
1-1/2 $4.30 1.80" 40 M915 16.20 90° Male 1-1/2" 1-1/2" Male IPS
Standard Length – 50 Feet MS15 14.90 Straight Male 1-1/2" 1-1/2" Male IPS
Bursting Pressure vs. Working Pressure = 4:1
For Conversion Table of Pipe Size O.D. to Hose Size I.D. — See The Last Pages of the Catalog
For Pipe To Hose Adapters — See Page 454 **For Hose Clamps — See Fig. 3191
