Parker Hose 737

PARKER 221FR BLUE
MARINE FUEL AND ENGINE HOSE

Construction
Fuel and oil-resistant synthetic rubber Ideal for
tube, one braid of high-tensile steel wire, use with
and blue oil, weather and fire-resistant Racor Filters
synthetic rubber cover. Layline is
embossed for permanent identification.
Applications and Temperature Range
• Gasoline, ethanol blends, diesel fuels, petroleum-base
hydraulic fluids and lubricating oils within a tempera-
ture range of -4°F to +212°F (-20°C to +100°C).
• Water, water/glycol, water/oil emulsion hydraulic fluids Versatile 221FR is designed for gasoline as well
up to +185°F (85°C). as diesel engine systems — also recommended
for oil lines, transmission fluid lines and petro-
The Fire-Resistant Hose for leum-based hydraulic fluids.
Gasoline or Diesel Systems
• Meets SAE J1527 Type A Class 1 and SAE J1942 standards.
• USCG accepted for commercial and recreational vessel applications.
• Meets Class 1 permeation requirements with gasoline and gasoline/ethanol blend.
• For the total advantage in marine fuel and engine hose, 221FR delivers test-proven performance in a wide operat-
ing temperature range, constant working pressure in six sizes, long-lasting reinforced construction, kink and cut
resistance and compatibility with a variety of standard 100R5 fittings.

Blue Parker 221FR Hose Mandrel Tool Kit – 22 Series

One of each of the parts listed
below are INCLUDED in the Kit
Hose Dash SAE (JIC)37° SAE 45°
I.D. Size Part Number Part Number
FIG 1PAR 3/16 4 5 631073-4 631073-4
631073-5
1/4
631073-5
Max. Min. 5/16 6 631073-6 631074-6
Per Working Burst Std. 13/32 10 8 631073-8 631073-8
631073-10
631073-10
1/2
No. Foot I.D. O.D. Pressure Pressure Length FIG 1PAR 5/8 12 631073-12 631074-12
221FR5 $11.65 1/4" .58" 500 psi 2000 psi 50 ft.
221FR6 14.40 5/16" .68" 500 psi 2000 psi 50 ft.
221FR8 13.45 13/32" .77" 500 psi 2000 psi 50 ft. The Mandrel Tool Kit is for assembling Parker 22 Series hose
221FR10 17.60 1/2" .92" 500 psi 2000 psi 50 ft. fittings. Example: 20622 is 22 Series, 20620 is 20 Series.
221FR12 19.10 5/8" 1.08" 500 psi 2000 psi 50 ft. No. Each Case
221FR16 19.20 7/8" 1.23" 500 psi 2000 psi 50 ft. 652200 $608.10 1
®
Jiffy Hose MSHA PARKER HOSE
Series 7212

FIG 2060b

This oil-resistant hose is for use with air tools to convey water, mild chemicals and various petroleum products. Light, flexible and
couples in a jiffy, no clamps or special tools needed. Has a special braid angle for quick and secure coupling retention. Flame-resis-
tant cover is branded with MSHA approval number. Temperature range: -40°F to 212°F. 4:1 safety factor. Maximum working pressure
for all: 300 PSI. Color: Blue.
No./I.D. Per Foot O.D. Length No./I.D. Per Foot O.D. Length
1/4 $2.20 1/2" 100 ft. 5/8 $5.05 29/32" 100 ft.
3/8 2.55 5/8" 100 ft. 3/4 5.35 1-1/32" 100 ft.
1/2 2.75 3/4" 100 ft.
