742 Vernalifts and Mufflers

Vernalifts – Style III

Except
1500051

B

A1 In A2 Out C

FIG 9292

This all fiberglass exhaust muffler is very effective in reducing engine exhaust noise, as well as preventing water return to the
exhaust manifold. Such properties are particularly important in engines which are installed near or below water line. Such installa-
tions are very common in sailing vessels or displacement hulls. The fire retardant Vernalift will not rust, corrode or deteriorate from
contact with exhaust gases. This type of horizontal Vernalift should be installed in a position equivalent to those as shown in the dia-
grams under Fig. 9291.
ALL DIMENSIONS ARE IN INCHES
No. Each A1 In* A2 Out* B C
1500042 $271.05 2.00 2.00 10.50 6.36
1500051 358.00 3.00 3.00 17.50 10.04
*OD dimensions
45° Vernalift – Style IV Rectangular Vernalift
For Small Narrow Areas

VERNALIFTS AND MUFFLERS B C A2 Out A1 In Style I Style II

FIG 9290

FIG 9225
This all fiberglass exhaust muffler is very effective in reducing
engine exhaust noise and preventing water return to the
exhaust manifold. Important in engines which are installed Manufactured in two pieces, a top and a base from RTM molds
near or below water line like in sailing vessels or displacement of continuous fiberglass mat. The body is smooth, strong and
hulls. The fire retardant Vernalift will not rust, corrode or dete- made of fire retardant, self-extinguishing resins. Available in
riorate from contact with exhaust gases. either Style I: Top In/Top Out or Style II: Side In/Top Out.
ALL DIMENSIONS ARE IN INCHES No. Each A* In/Out Height Width Length Style
No. Each A1 In A2 Out B C 15R1200 $350.80 2.00 7.0 7.0 12.0 I
1500107 $289.50 2.00 2.00 10.16 10.04 15R2150 338.90 1.50 7.0 7.0 12.0 II
1500112 395.90 3.00 3.00 12.00 12.34* 15R2200 350.80 2.00 7.0 7.0 12.0 II
*Bases On These Models Are Square *OD dimensions
