Page 498 - Lewis

Hynautic Steering Accessories 497

FIG 1HYN
Unless Noted

Hydraulic Fluids HYNAUTIC MCT 5/16" O.D. NYLON TUBING

TUBING CONSTRUCTION
Solid Wall, 5/16" O.D. (.23" I.D.) Unplasticized Nylon
Tubing, Using Special Mechanical Fittings

Hynautic 5/16" O.D. Nylon Tubing is recommended
for all engine control systems.
MCO2G HA5455
FOR STEERING SYSTEMS ONLY
AEROSHELL FLUID 4 HYDRAULIC FLUID SEASTAR 1 STEERING TUBE 502
Each Size Description
Fig. 1HYN No. MCO2G $70.35 Gallon Red Steering Fluid
Tubing
FOR CONTROL SYSTEMS ONLY
50/50 WATER/PURE ETHYLENE GLYCOL
Each Size Description
Fig. 6564 No. HA5455 $74.65 Gallon Shift & Throttle Fluid 3/8" 3/16" SeaStar 1 Steering Tube 502
HYDRAULIC FLUID
Each Size Description
Fig. 6564 No. HA5430 $32.80 Quart SeaStar No. Roll Description
Hydraulic Fluid Fig. 6564 No. HT5095 $129.15 50 Feet of 3/8" OD Nylon Tubing
Fig. 6564 No. HA5440 104.85 Gallon SeaStar Fig. 6564 No. HT5100 252.20 100 Feet of 3/8" OD Nylon Tubing
Hydraulic Fluid WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
Hydraulic Tubing and Hose TUBING CONSTRUCTION
No. Per Roll Description Solid Wall, 3/8" O.D. (3/16" I.D.)
MCT01 $79.65 5/16" O.D. x 50 ft. Nylon Tubing Unplasticized Nylon Tubing, Using
MCT02 151.65 5/16" O.D. x 100 ft. Nylon Tubing Special Mechanical Fittings
MSH5 3.30 5/16" ID Reinforced Hose Per Foot 950 psi
MSH5-50 187.25 5/16" I.D. x 50 ft Reinforced Hose
MSH5-100 374.50 5/16" I.D. x 100 ft. Reinforced Hose HYNAUTIC MSH5 5/16" I.D.
MSH5-600 1865.25 5/16" I.D. x 600 ft. Reinforced Hose REINFORCED HOSE
MSH6 5.70 3/8" ID Reinforced Hose Per Foot 950 psi
MSH6-50 322.20 3/8" I.D. x 50 ft. Reinforced Hose
MSH6-100 644.45 3/8" I.D. x 100 ft. Reinforced Hose TUBING CONSTRUCTION
MSH6-600 3192.40 3/8" I.D. x 600 ft. Reinforced Hose A composite hose consisting of a seamless nylon core
SOLD IN FULL ROLLS ONLY tube, reinforced with a synthetic fiber braid, bonded to
For Copper Tubing — See Fig. 3588
a polyurethane outer cover. This hose is specially com-
WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov
pounded for maximum flexibility and resistance to salt
Hose Bend Restrictors water, internal fluids, abrasion and direct sunlight.
Brass end fittings can be either swage or reusable
type, -6 SAE female swivel.
Size I.D. O.D. Max. Working Min. Burst Min. Bend
Hose in. (mm) in. (mm) Pressure Pressure Radius
Increases strength at the hose and fitting connection to help MSH5 5/16 (8) 1/2 (11.8) 1000psi 4000psi 2-1/4"
avoid kinking the hose. MSH6 3/8 (9.5) 5/8 (14.5) 1000psi 4000psi 3"
No. Each Use With
HBR4 $6.55 MSH5 Nylon Tubing Hynautic MSH5 (5/16" I.D.) Reinforced Hose HYNAUTIC STEERING ACCESS.
HBR6 7.80 MSH6 Nylon Tubing is used with those steering sytems which require the
950 psi relief valve. It is recommended on all boats
Bulkhead Strain Relief Hose Kit of a standard design which might otherwise use 3/8"
O.D. copper tubing (consult steering literature).

FIG 4186 Hynautic MSH6 (3/8" I.D.) Reinforced Hose
is recommended for performance boats and other
yachts which normally require 1/2" O.D. copper
This kit distributes strain from bends in
hose, has a watertight gripper fitting and lines and use the Hynautic 40 series helm unit.
the bulkhead fitting has a flange for protec-
tion. Great for hydraulic steering. Flange
diameter: 2-3/4". Use 1-1/4" installation hole. HYNAUTIC MSH6 3/8" I.D.
No. Each Color REINFORCED HOSE
BSR-1K $21.90 Black
